Street Light LED MASTER STREET 35W 4000K IP66 WB Kobi Pro

Go back
Symbol:
001691
EAN:
5902201371215
To know about the inventory, prices
and be able to place orders, log in.
Product description



  • body made of aluminium, cover made of tempered glass,
  • a possibility of verical / horizontal fixture's installation,
  • a possibility of adjusting the fixture of 15 degrees,
  • installation on pilars Ø60 mm,
  • with NEMA 5P socket, on which the end cap needs to be installed (included),
  • possibility of adjusting the power of the fixture on request,
  • fixture includes light sources of energy class: B,
  • the LED light source can only be replaced by qualified personnel.







MODEL INDEX POWER [W] BEAM ANGLE COLOR TEMPERATURE [K] LUMINOUS FLUX [lm] NET WEIGHT [kg] PACKING [pcs.] BARCODE
MASTER STREET S 35W WB 001691 35 160°x160° PARKING 4000 5950 3,30 1 5902201371215



Specification
Beam angle [degrees]
160
Brand
Kobi Professional
Certifications
LVD
EMC
ROHS
ERP
Class of resistance against dust and humidity [IP]
IP66
Color Rendering Index
Ra ≥70
Color temperature [K]
4000
Control options
TAK
EEI
B
Eprel
1852383
Fixture type
inwestycyjna
Installation
na słupie
Klasa źródła w oprawie
B
Light source’s life span [h]
80000
Luminous flux [lm]
5950
On/off cycles
30000
Power [W]
35
Product color
szary
Protection degree against mechanical damages [IK]
IK09
Voltage
230
Warranty in years
5 lat
Working temperature
-30
+45
Files to download
Files to download
Product card
User manual
Declaration of conformity
declaration-of-conformity-no-576-2024-master-street-s-e0e998b2.pdf
Photometric data file
